Bimba "Original" Stainless Steel Pneumatic Cylinder to Parker Series SR

Download CAD Files

NOTE: this website is meant to assist the conversion of existing standard Bimba model numbers. Some model numbers may require assistance from Parker personnel. While every attempt has been made to proof this website's output, accuracy is not guaranteed. Please check catalog AU03-0900P-3/NA for verification of proper model number conversion.

Use the catalog or the SR eConfigurators in PHconnect for new model number generation.

Bimba Original Stainless Steel Pneumatic Cylinder to Parker Series SR

Complete the Bimba model number for the equivalent SR model number:

CUSHIONSTYPEMAGNETSSTAINLESS STEEL RODSBORESTROKEMOUNTING STYLEOPTIONSOPTIONSOPTIONSOPTIONSOPTIONS

Results:

Bimba Model Number:

Parker SR Model Number:

Clear All Data

Mechanical Drawing
CodeDescription
NNose mount, spring return
NRNose mount, spring return, hex rod (non-rotating)
NRPPivot and nose mount, spring return, hex rod (non-rotating)
PPivot mount, spring return
RNose mount, spring extended
RPPivot and nose mount, spirng extend
DNose mount, double acting
DPPivot and nose mount, double acting, no pivot pin
DXPPivot and nose mount, double acting, no pivot pin
DXThreaded both ends, double acting
KDXThreaded both ends, double acting, double rod
KDXHThreaded both ends, double rod, hollow rod
ANose mout, sprig return, head adjustable stroke
RANose mount, spring extend, cap adjustable
APPivot mount, spring reutrn, head adjustable stroke
BFDFront block mount, double acting
BRDRear block mount, double acting
ARAir reservoirs
TFDFront trunnion mount, double acting
TRDRear trunnion mount, double acting
BFNFront block mount, single acting, spring return
BFRFront block mount, single acting, spring extend
BRNRear block mount, single acting
TRNRear trunnion mount, single acting, spring return

Bimba is a registered trademark of the Bimba Manufacturing Company
